| ◇ 제품정보 ◇ |
▒ 5008BCM4 ▒ |
|
|
| | Model |
: |
8 |
|
| | SPEC |
: |
85 |
|
| | Remark1 |
: |
450 |
|
| | Remark2 |
: |
Fo ~ 5K |
|
| | Remark3 |
: |
1.0 |
|
| | Remark4 |
: |
2.0 |
|
| |
|
|
|
 |
5008BCM4
| 5008BCM4 |
|
|
Model |
5008BCM4 |
Type |
Micro Dynamic
Conepaper Speaker |
Diameter |
50 ± 0.2 [mm] |
Thickness |
11.0 ± 0.2 [mm] |
Impedance |
8 ± 15% [] |
S.P.L |
85 ± 3 [dB] at 1[W] 1[m] |
Fo |
450 [Hz] |
Frequency range |
Fo ~ 5K [Hz] |
Operation |
1.0 [W] , 2.83 [V] |
RMS power |
1.0 [W] |
MAX power |
2.0 [W] |
Magnet type |
Nd-Fe-B |
|
|
|
|
|
|
|
|
)
